[ENG-1848] Add Roam full markdown content variant for shared nodes #1134
+336
−20
There are no files selected for viewing
This file contains hidden or bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters.
Learn more about bidirectional Unicode characters
This file contains hidden or bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters.
Learn more about bidirectional Unicode characters
| Original file line number | Diff line number | Diff line change |
|---|---|---|
| @@ -0,0 +1,233 @@ | ||
| import type { TreeNode } from "roamjs-components/types"; | ||
| import type { CrossAppNode } from "@repo/database/crossAppNodeContract"; | ||
| import { buildFullMarkdown } from "./convertRoamNodeToFullContent"; | ||
|
|
||
| /** | ||
| * Typed example for ENG-1848 ("tests or fixtures cover representative Roam | ||
| * block content becoming `full` markdown"). This is not a concrete test; it | ||
| * documents the `tree.children` shape returned by `getFullTreeByParentUid` for | ||
| * a real Roam claim page and type-checks the generated markdown against the | ||
| * contract. | ||
| * | ||
| * Derived from: | ||
| * https://roamresearch.com/#/app/plugin-testing-akamatsulab2/page/dnHNmYwe5 | ||
| * | ||
| * Observed markdown output: | ||
| * | ||
| * # [[CLM]] - Actin assembly peaks 8 seconds before endocytic scission | ||
| * | ||
| * - ## Source of Claim [ℹ](link to [[@source]], name, URL, etc) | ||
| * - [[[[EVD]] - Membrane invagination occurred ~6 seconds after scission protein (spHob1-GFP) was detected in budding yeast cells - [[@sun2019direct]]]] | ||
| * - [[[[EVD]] - At fission yeast endocytic sites, scission protein (spHob1) first detected ~2 seconds before initiation of membrane invagination - [[@sun2019direct]]]] | ||
| * - [[[[EVD]] - Actin appearance occurred 9 (+/-2) seconds prior to patch formation and disappears 10 (+/-2) seconds following patch development. [[@sirotkin2010quantitative]]]] | ||
| * - [[[[EVD]] - At zero seconds, 7000 actin proteins associated with endocytic invagination - [[@sirotkin2010quantitative]]]] | ||
| * - actin assembly peaks (x) seconds before/after endocytic scission | ||
| * - [[[[CLM]] - Actin assembly peaks 8 seconds before endocytic scission]] | ||
| * - ## Notes | ||
| * -  | ||
| */ | ||
|
|
||
| type SerializedTreeNode = Omit<TreeNode, "children" | "editTime"> & { | ||
| children: SerializedTreeNode[]; | ||
| editTime: string; | ||
| }; | ||
|
|
||
| const deserializeTreeNode = (node: SerializedTreeNode): TreeNode => ({ | ||
| ...node, | ||
| editTime: new Date(node.editTime), | ||
| children: node.children.map(deserializeTreeNode), | ||
| }); | ||
|
|
||
| const title = | ||
| "[[CLM]] - Actin assembly peaks 8 seconds before endocytic scission"; | ||
|
|
||
| const serializedBlocks: SerializedTreeNode[] = [ | ||
| { | ||
| text: "Source of Claim [ℹ](((JtVWq1Cwl)))", | ||
| open: true, | ||
| order: 0, | ||
| uid: "yxM5yI07g", | ||
| heading: 2, | ||
| viewType: "bullet", | ||
| blockViewType: "outline", | ||
| editTime: "2024-02-29T21:28:17.505Z", | ||
| props: { | ||
| imageResize: {}, | ||
| iframe: {}, | ||
| }, | ||
| textAlign: "left", | ||
| children: [ | ||
| { | ||
| text: "[[[[EVD]] - Membrane invagination occurred ~6 seconds after scission protein (spHob1-GFP) was detected in budding yeast cells - [[@sun2019direct]]]]", | ||
| open: true, | ||
| order: 0, | ||
| uid: "tZnNCIgsk", | ||
| heading: 0, | ||
| viewType: "bullet", | ||
| blockViewType: "outline", | ||
| editTime: "2024-03-25T05:40:43.601Z", | ||
| props: { | ||
| imageResize: {}, | ||
| iframe: {}, | ||
| }, | ||
| textAlign: "left", | ||
| children: [], | ||
| parents: [0], | ||
| }, | ||
| { | ||
| text: "[[[[EVD]] - At fission yeast endocytic sites, scission protein (spHob1) first detected ~2 seconds before initiation of membrane invagination - [[@sun2019direct]]]]", | ||
| open: true, | ||
| order: 1, | ||
| uid: "i-rS06THC", | ||
| heading: 0, | ||
| viewType: "bullet", | ||
| blockViewType: "outline", | ||
| editTime: "2024-02-29T21:38:44.920Z", | ||
| props: { | ||
| imageResize: {}, | ||
| iframe: {}, | ||
| }, | ||
| textAlign: "left", | ||
| children: [], | ||
| parents: [0], | ||
| }, | ||
| { | ||
| text: "[[[[EVD]] - Actin appearance occurred 9 (+/-2) seconds prior to patch formation and disappears 10 (+/-2) seconds following patch development. [[@sirotkin2010quantitative]]]]", | ||
| open: true, | ||
| order: 2, | ||
| uid: "fiWpNvVM8", | ||
| heading: 0, | ||
| viewType: "bullet", | ||
| blockViewType: "outline", | ||
| editTime: "2024-02-29T21:38:54.473Z", | ||
| props: { | ||
| imageResize: {}, | ||
| iframe: {}, | ||
| }, | ||
| textAlign: "left", | ||
| children: [], | ||
| parents: [0], | ||
| }, | ||
| { | ||
| text: "[[[[EVD]] - At zero seconds, 7000 actin proteins associated with endocytic invagination - [[@sirotkin2010quantitative]]]]", | ||
| open: true, | ||
| order: 3, | ||
| uid: "nz8-Sd5a5", | ||
| heading: 0, | ||
| viewType: "bullet", | ||
| blockViewType: "outline", | ||
| editTime: "2024-02-29T21:39:03.540Z", | ||
| props: { | ||
| imageResize: {}, | ||
| iframe: {}, | ||
| }, | ||
| textAlign: "left", | ||
| children: [], | ||
| parents: [0], | ||
| }, | ||
| { | ||
| text: "", | ||
| open: true, | ||
| order: 4, | ||
| uid: "fEcOIBDD7", | ||
| heading: 0, | ||
| viewType: "bullet", | ||
| blockViewType: "outline", | ||
| editTime: "2024-02-29T21:39:31.790Z", | ||
| props: { | ||
| imageResize: {}, | ||
| iframe: {}, | ||
| }, | ||
| textAlign: "left", | ||
| children: [], | ||
| parents: [0], | ||
| }, | ||
| { | ||
| text: "actin assembly peaks (x) seconds before/after endocytic scission", | ||
| open: true, | ||
| order: 5, | ||
| uid: "xgfRsZ-Xb", | ||
| heading: 0, | ||
| viewType: "bullet", | ||
| blockViewType: "outline", | ||
| editTime: "2024-02-29T21:38:25.591Z", | ||
| props: { | ||
| imageResize: {}, | ||
| iframe: {}, | ||
| }, | ||
| textAlign: "left", | ||
| children: [ | ||
| { | ||
| text: "[[[[CLM]] - Actin assembly peaks 8 seconds before endocytic scission]]", | ||
| open: true, | ||
| order: 0, | ||
| uid: "URYHjVOwB", | ||
| heading: 0, | ||
| viewType: "bullet", | ||
| blockViewType: "outline", | ||
| editTime: "2024-02-29T21:48:24.324Z", | ||
| props: { | ||
| imageResize: {}, | ||
| iframe: {}, | ||
| }, | ||
| textAlign: "left", | ||
| children: [], | ||
| parents: [0], | ||
| }, | ||
| ], | ||
| parents: [0], | ||
| }, | ||
| ], | ||
| parents: [], | ||
| }, | ||
| { | ||
| text: "Notes", | ||
| open: true, | ||
| order: 1, | ||
| uid: "LVRwULrGC", | ||
| heading: 2, | ||
| viewType: "bullet", | ||
| blockViewType: "outline", | ||
| editTime: "2024-02-29T21:28:17.509Z", | ||
| props: { | ||
| imageResize: {}, | ||
| iframe: {}, | ||
| }, | ||
| textAlign: "left", | ||
| children: [ | ||
| { | ||
| text: "", | ||
| open: true, | ||
| order: 0, | ||
| uid: "aMAPTRui2", | ||
| heading: 0, | ||
| viewType: "bullet", | ||
| blockViewType: "outline", | ||
| editTime: "2024-03-07T22:57:13.411Z", | ||
| props: { | ||
| imageResize: {}, | ||
| iframe: {}, | ||
| }, | ||
| textAlign: "left", | ||
| children: [], | ||
| parents: [0], | ||
| }, | ||
| ], | ||
| parents: [], | ||
| }, | ||
| ]; | ||
|
|
||
| const blocks = serializedBlocks.map(deserializeTreeNode); | ||
|
|
||
| export const roamClaimFullMarkdownExample: { | ||
| title: string; | ||
| blocks: TreeNode[]; | ||
| full: CrossAppNode["content"]["full"]; | ||
| } = { | ||
| title, | ||
| blocks, | ||
| full: { | ||
| format: "text/markdown", | ||
| value: buildFullMarkdown({ title, blocks }), | ||
| }, | ||
| }; |
This file contains hidden or bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters.
Learn more about bidirectional Unicode characters
| Original file line number | Diff line number | Diff line change |
|---|---|---|
| @@ -0,0 +1,68 @@ | ||
| import { toMarkdown } from "./pageToMarkdown"; | ||
| import { type RoamDiscourseNodeData } from "./getAllDiscourseNodesSince"; | ||
| import { type DiscourseNode } from "./getDiscourseNodes"; | ||
| import getFullTreeByParentUid from "roamjs-components/queries/getFullTreeByParentUid"; | ||
| import getPageViewType from "roamjs-components/queries/getPageViewType"; | ||
| import type { TreeNode, ViewType } from "roamjs-components/types"; | ||
| import type { LocalContentDataInput } from "@repo/database/inputTypes"; | ||
|
|
||
| const FULL_MARKDOWN_OPTS = { | ||
| refs: true, | ||
| embeds: true, | ||
| simplifiedFilename: false, | ||
| removeSpecialCharacters: false, | ||
| maxFilenameLength: 64, | ||
| linkType: "alias", | ||
| allNodes: [] as DiscourseNode[], | ||
| }; | ||
|
|
||
| export const buildFullMarkdown = ({ | ||
| title, | ||
| blocks, | ||
| viewType = "bullet", | ||
| }: { | ||
| title: string; | ||
| blocks: TreeNode[]; | ||
| viewType?: ViewType; | ||
| }): string => { | ||
| const body = blocks | ||
| .filter((block) => !!block.text || !!block.children?.length) | ||
| .map((block) => | ||
| toMarkdown({ c: block, v: viewType, i: 0, opts: FULL_MARKDOWN_OPTS }), | ||
| ) | ||
| .join("\n") | ||
| .trim(); | ||
| return body ? `# ${title}\n\n${body}\n` : `# ${title}\n`; | ||
| }; | ||
|
|
||
| export const convertRoamNodeToFullContent = ({ | ||
| nodes, | ||
| }: { | ||
| nodes: RoamDiscourseNodeData[]; | ||
| }): LocalContentDataInput[] => | ||
| nodes.flatMap((node) => { | ||
| try { | ||
| const title = node.node_title ?? node.text; | ||
| const blocks = getFullTreeByParentUid(node.source_local_id).children; | ||
| const viewType = getPageViewType(title) || "bullet"; | ||
| return [ | ||
| { | ||
| author_local_id: node.author_local_id, | ||
| source_local_id: node.source_local_id, | ||
| created: new Date(node.created || Date.now()).toISOString(), | ||
| last_modified: new Date( | ||
| node.last_modified || Date.now(), | ||
| ).toISOString(), | ||
| text: buildFullMarkdown({ title, blocks, viewType }), | ||
| variant: "full", | ||
| scale: "document", | ||
| }, | ||
| ]; | ||
| } catch (error) { | ||
| console.error( | ||
| `convertRoamNodeToFullContent: failed to build full markdown for ${node.source_local_id}:`, | ||
| error, | ||
| ); | ||
| return []; | ||
|
Comment on lines
+61
to
+66
Contributor
There was a problem hiding this comment. 🚩 Full content silently skipped on error doesn't propagate to caller When
Was this helpful? React with 👍 or 👎 to provide feedback. |
||
| } | ||
| }); | ||
Oops, something went wrong.
Add this suggestion to a batch that can be applied as a single commit.
This suggestion is invalid because no changes were made to the code.
Suggestions cannot be applied while the pull request is closed.
Suggestions cannot be applied while viewing a subset of changes.
Only one suggestion per line can be applied in a batch.
Add this suggestion to a batch that can be applied as a single commit.
Applying suggestions on deleted lines is not supported.
You must change the existing code in this line in order to create a valid suggestion.
Outdated suggestions cannot be applied.
This suggestion has been applied or marked resolved.
Suggestions cannot be applied from pending reviews.
Suggestions cannot be applied on multi-line comments.
Suggestions cannot be applied while the pull request is queued to merge.
Suggestion cannot be applied right now. Please check back later.
There was a problem hiding this comment.
Choose a reason for hiding this comment
The reason will be displayed to describe this comment to others. Learn more.
For node types backed by an Embedding Block Ref,
getDiscourseNodeTypeWithSettingsBlockNodessetssource_local_idto the child block UID and stores that block's text innode.text; reading only.childrenhere serializes descendants but drops the source block itself. A block-backed discourse node with no children now uploads# <page title>as itsfullcontent, and one with children still omits the actual claim/evidence text, so imported materializations are incomplete.Useful? React with 👍 / 👎.
