Azure Cheatsheet

text

1. Introduction:

  • Microsoft Azure is a cloud computing platform offering a wide range of services, including compute, analytics, storage, and networking.

2. Core Azure Services:

  • Compute:

    • Azure Virtual Machines:

      • Scalable virtual servers for running applications.

      • Key Concepts: VM Sizes, Resource Groups, Virtual Networks, Disks.

      • Example:

        az vm create --resource-group myResourceGroup --name myVM --image UbuntuLTS --admin-username azureuser --generate-ssh-keys

    • Azure Functions:

      • Serverless compute service for running event-driven code.

      • Key Concepts: Functions, Triggers, Bindings.

      • Example:

        func init MyFunctionProj --dotnet
func new --name MyHttpTrigger --template "HTTP trigger" --authlevel "anonymous"

    • Azure Kubernetes Service (AKS):

      • Managed Kubernetes service for running containerized applications.

      • Key Concepts: Clusters, Nodes, Pods, Services.

      • Example:

        az aks create --resource-group myResourceGroup --name myAKSCluster --node-count 1 --enable-addons monitoring --generate-ssh-keys

  • Storage:

    • Azure Blob Storage:

      • Object storage solution for the cloud.

      • Key Concepts: Storage Accounts, Containers, Blobs, Access Tiers.

      • Example:

        az storage account create --name mystorageaccount --resource-group myResourceGroup --location eastus --sku Standard_LRS
az storage container create --name mycontainer --account-name mystorageaccount
az storage blob upload --container-name mycontainer --file myfile.txt --name myfile.txt --account-name mystorageaccount

    • Azure Files:

      • Managed file shares in the cloud using the SMB protocol.

      • Key Concepts: File Shares, Directories, Snapshots.

      • Example:

        az storage share create --name myshare --account-name mystorageaccount

    • Azure Disk Storage:

      • High-performance disk storage for VMs.

      • Key Concepts: Managed Disks, Disk Types (Standard HDD, Standard SSD, Premium SSD).

      • Example:

        az disk create --resource-group myResourceGroup --name myDisk --size-gb 128 --sku Premium_LRS

  • Database:

    • Azure SQL Database:

      • Managed relational database service.

      • Key Concepts: Databases, Servers, Elastic Pools, DTUs/vCores.

      • Example:

        az sql db create --resource-group myResourceGroup --server myServer --name myDatabase --service-objective S0

    • Cosmos DB:

      • Globally distributed, multi-model database service.

      • Key Concepts: Databases, Containers, Partition Keys, Consistency Levels.

      • Example:

        az cosmosdb create --name myCosmosDBAccount --resource-group myResourceGroup --kind MongoDB --locations regionName=eastus

    • Azure Database for MySQL/PostgreSQL:

      • Managed MySQL/PostgreSQL service.

      • Key Concepts: Servers, Databases, Backup Retention, Performance Tiers.

      • Example:

        az mysql server create --resource-group myResourceGroup --name mydemoserver --location eastus --admin-user myadmin --admin-password mypassword --sku-name GP_Gen5_2

3. Networking:

  • Azure Virtual Network (VNet):

    • Provides an isolated network environment in Azure.

    • Key Concepts: Subnets, Network Security Groups, VPN Gateway, Peering.

    • Example:

      az network vnet create --resource-group myResourceGroup --name myVnet --address-prefix 10.0.0.0/16 --subnet-name mySubnet --subnet-prefix 10.0.1.0/24

  • Azure Load Balancer:

    • Distributes inbound traffic across multiple VMs.

    • Key Concepts: Frontend IP, Backend Pools, Load Balancing Rules.

    • Example:

      az network lb create --resource-group myResourceGroup --name myLoadBalancer --frontend-ip-name myFrontEnd --backend-pool-name myBackEndPool

  • Azure Application Gateway:

    • Web traffic load balancer for managing HTTP and HTTPS traffic.

    • Key Concepts: Listener, Rules, HTTP Settings, SSL Certificates.

    • Example:

      az network application-gateway create --name myAppGateway --resource-group myResourceGroup --capacity 2 --sku Standard_v2 --vnet-name myVnet --subnet mySubnet

  • Azure DNS:

    • Hosts your DNS domains and provides name resolution using Microsoft Azure infrastructure.

    • Key Concepts: DNS Zones, Records, NS Records, A Records.

    • Example:

      az network dns zone create --resource-group myResourceGroup --name mydomain.com
az network dns record-set a add-record --resource-group myResourceGroup --zone-name mydomain.com --record-set-name www --ipv4-address 10.0.0.4

4. Security and Identity:

  • Azure Active Directory (AAD):

    • Identity and access management service.

    • Key Concepts: Users, Groups, Roles, Managed Identities, Conditional Access.

    • Example:

      az ad user create --display-name "My User" --user-principal-name myuser@mydomain.com --password "P@ssw0rd!"

  • Azure Key Vault:

    • Securely store and access secrets, keys, and certificates.

    • Key Concepts: Vaults, Secrets, Keys, Certificates, Access Policies.

    • Example:

      az keyvault create --name myKeyVault --resource-group myResourceGroup --location eastus
az keyvault secret set --vault-name myKeyVault --name MySecret --value "MySecretValue"

  • Azure Security Center:

    • Unified infrastructure security management system.

    • Key Concepts: Security Posture, Recommendations, Secure Score, Just-in-Time VM Access.

    • Example:

      az security assessment create --name myAssessment --status "Healthy" --description "This is a custom assessment."

  • Azure Policy:

    • Enforce organizational standards and assess compliance at-scale.

    • Key Concepts: Definitions, Initiatives, Assignments.

    • Example:

      az policy assignment create --name myPolicyAssignment --scope /subscriptions/{subscription-id}/resourceGroups/{resource-group-name} --policy /subscriptions/{subscription-id}/providers/Microsoft.Authorization/policyDefinitions/{policyDefinitionName}

5. Management Tools:

  • Azure Resource Manager (ARM):

    • Azure’s deployment and management service.

    • Key Concepts: ARM Templates, Resources, Resource Groups, Deployments.

    • Example:

      az group create --name myResourceGroup --location eastus
az deployment group create --resource-group myResourceGroup --template-file azuredeploy.json

  • Azure Monitor:

    • Comprehensive monitoring service for collecting, analyzing, and acting on telemetry data.

    • Key Concepts: Metrics, Logs, Alerts, Application Insights, Log Analytics.

    • Example:

      az monitor alert create --name myAlert --resource-group myResourceGroup --target /subscriptions/{subscription-id}/resourceGroups/{resource-group-name}/providers/Microsoft.Compute/virtualMachines/{vm-name} --condition "avg Percentage CPU > 75"

  • Azure Automation:

    • Automate frequent, time-consuming, and error-prone cloud management tasks.

    • Key Concepts: Runbooks, Desired State Configuration (DSC), Hybrid Worker Groups.

    • Example:

      az automation account create --name myAutomationAccount --resource-group myResourceGroup --location eastus
az automation runbook create --name myRunbook --automation-account-name myAutomationAccount --resource-group myResourceGroup --type PowerShellWorkflow

  • Azure Advisor:

    • Personalized cloud consultant that helps you follow best practices to optimize your Azure deployments.
    • Key Concepts: Recommendations, Cost, Performance, Security, High Availability.
    • Example:
      • Access via Azure Portal.

6. Advanced Topics:

  • Cost Management:

    • Monitor and optimize your Azure costs using Cost Management + Billing.

    • Example:

      az consumption budget create --amount 1000 --time-grain Monthly --start-date 2024-08-

01 --end-date 2024-08-31 --name myBudget --resource-group myResourceGroup ```

  • Auto Scaling:

    • Automatically adjust the number of VM instances based on demand.

    • Key Concepts: Scale Sets, Scaling Rules, Metrics.

    • Example:

      az vmss create --resource-group myResourceGroup --name myScaleSet --image UbuntuLTS --upgrade-policy-mode automatic --admin-username azureuser --generate-ssh-keys

  • Serverless Architectures:

    • Utilize Azure Functions, Logic Apps, and Event Grid for serverless solutions.

    • Key Concepts: Triggers, Bindings, Workflows, Event Subscriptions.

    • Example:

      az eventgrid event-subscription create --name myEventSubscription --source-resource-id /subscriptions/{subscription-id}/resourceGroups/{resource-group}/providers/Microsoft.Storage/storageAccounts/{storage-account-name} --endpoint https://myfunction.azurewebsites.net/runtime/webhooks/eventgrid?functionName=myfunction

7. Best Practices:

  • Security:

    • Use Azure Security Center, encrypt data, apply RBAC, monitor with Azure Monitor, and implement secure coding practices.

  • Reliability:

    • Use Availability Sets, Availability Zones, configure backups, and utilize disaster recovery services.

  • Performance Efficiency:

    • Choose appropriate VM sizes, use caching services, and optimize databases.

  • Cost Optimization:

    • Use Reserved Instances (RIs), monitor spend, and optimize resources.

  • Operational Excellence:

    • Automate deployments with ARM, monitor operations, and use infrastructure as code (IaC).
