Kubernetes Cheatsheet

Checkout detailed article on Dev.to

1. Introduction to Kubernetes

What is Kubernetes?

Kubernetes is an open-source container orchestration platform that automates the deployment, scaling, and management of containerized applications.

Key Concepts

Cluster: A set of worker machines, called nodes, that run containerized applications.
Node: A single machine in a Kubernetes cluster.
Pod: The smallest deployable unit, which can contain one or more containers.
Service: A stable network endpoint to expose a set of pods.
Namespace: A way to divide cluster resources between multiple users.
Kubelet: An agent running on each node that ensures containers are running in a Pod.
Kubectl: Command-line tool to interact with Kubernetes clusters.

2. Basic Kubernetes Operations

Setting Up a Kubernetes Cluster

Minikube: Set up a single-node Kubernetes cluster for testing.
```
minikube start
```

Working with `kubectl`

Get Cluster Information:
```
kubectl cluster-info
```
Get All Nodes in the Cluster:
```
kubectl get nodes
```

Managing Pods

Create a Pod:
```
kubectl run mypod --image=nginx
```
List All Pods:
```
kubectl get pods
```
Describe a Pod:
```
kubectl describe pod mypod
```
Delete a Pod:
```
kubectl delete pod mypod
```

Using Namespaces

List All Namespaces:
```
kubectl get namespaces
```
Create a Namespace:
```
kubectl create namespace mynamespace
```
Delete a Namespace:
```
kubectl delete namespace mynamespace
```

3. Deployments and Scaling

Deployments

Create a Deployment:

kubectl create deployment myapp --image=nginx

View Deployment Status:
```
kubectl get deployments
```

Update a Deployment:

kubectl set image deployment/myapp nginx=nginx:1.16

Rollback a Deployment:
```
kubectl rollout undo deployment/myapp
```

Scaling Applications

Scale a Deployment:

kubectl scale deployment myapp --replicas=3

Auto-scaling with Horizontal Pod Autoscaler (HPA):

kubectl autoscale deployment myapp --min=1 --max=5 --cpu-percent=80

4. Services and Networking

Services

Expose a Pod with a Service:

kubectl expose pod mypod --port=80 --target-port=8080

Create a Service for a Deployment:

kubectl expose deployment myapp --type=NodePort --port=80

List All Services:
```
kubectl get services
```

Networking

Understanding Cluster Networking: Kubernetes abstracts network communication between Pods.

Network Policies: Restrict Pod communication using Network Policies.

apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: mynetworkpolicy
  namespace: mynamespace
spec:
  podSelector:
    matchLabels:
      role: db
  policyTypes:
  - Ingress
  - Egress
  ingress:
  - from:
    - podSelector:
        matchLabels:
          role: frontend
  egress:
  - to:
    - podSelector:
        matchLabels:
          role: backend

5. Persistent Storage

Volumes

Create a Persistent Volume:

apiVersion: v1
kind: PersistentVolume
metadata:
  name: mypv
spec:
  capacity:
    storage: 1Gi
  accessModes:
    - ReadWriteOnce
  hostPath:
    path: "/mnt/data"

Create a Persistent Volume Claim:

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: mypvc
spec:
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 1Gi

StorageClasses

Create a StorageClass:

apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: mystorageclass
provisioner: kubernetes.io/aws-ebs
parameters:
  type: gp2

6. ConfigMaps and Secrets

ConfigMaps

Create a ConfigMap from a File:

kubectl create configmap myconfig --from-file=config.txt

View a ConfigMap:
```
kubectl get configmap myconfig -o yaml
```

Use a ConfigMap in a Pod:

apiVersion: v1
kind: Pod
metadata:
  name: mypod
spec:
  containers:
  - name: mycontainer
    image: nginx
    envFrom:
    - configMapRef:
        name: myconfig

Secrets

Create a Secret from a Literal Value:

kubectl create secret generic mysecret --from-literal=username=admin

View a Secret:
```
kubectl get secret mysecret -o yaml
```

Use a Secret in a Pod:

apiVersion: v1
kind: Pod
metadata:
  name: mypod
spec:
  containers:
  - name: mycontainer
    image: nginx
    envFrom:
    - secretRef:
        name: mysecret

7. Ingress Controllers

Setting Up Ingress

Install an Ingress Controller: Use a Helm chart or YAML manifest to install an ingress controller (e.g., NGINX Ingress Controller).
```
kubectl apply -f https://raw.githubusercontent.com/kubernetes/ingress-nginx/main/deploy/static/provider/cloud/deploy.yaml
```

Configuring Ingress Resources

Create an Ingress Resource:

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: myingress
spec:
  rules:
  - host: myapp.example.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: myapp-service
            port:
              number: 80

TLS Termination with Ingress:

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: myingress
spec:
  tls:
  - hosts:
    - myapp.example.com
    secretName: mytlssecret
  rules:
  - host: myapp.example.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: myapp-service
            port:
              number: 80

8. Kubernetes Security

Role-Based Access Control (RBAC)

Create a Role:

apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
  namespace: mynamespace
  name: myrole
rules:
- apiGroups: [""]
  resources: ["pods"]
  verbs: ["get", "watch", "list"]

Bind a Role to a User:

apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
  name: myrolebinding
  namespace: mynamespace
subjects:
- kind: User
  name: myuser
  apiGroup: rbac.authorization.k8s.io
roleRef:
  kind: Role
  name: myrole
  apiGroup: rbac.authorization.k8s.io

Pod Security Policies (PSP)

Create a PSP:

apiVersion: policy/v1beta1
kind: PodSecurityPolicy
metadata:
  name: mypsp
spec:
  privileged: false
  seLinux:
    rule: RunAsAny
  supplementalGroups:
    rule: RunAsAny
  runAsUser:
    rule: RunAsAny
  fsGroup:
    rule: RunAsAny
  volumes:
  - '*'

Network Policies

Create a Network Policy:

apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: allow-db
  namespace: mynamespace
spec:
  podSelector:
    matchLabels:
      role: db
  policyTypes:


  - Ingress
  ingress:
  - from:
    - podSelector:
        matchLabels:
          role: frontend

Securing Kubernetes API Server

Enable API Server Auditing:

Edit the API server manifest to include auditing options.

- --audit-log-path=/var/log/kubernetes/audit.log
- --audit-policy-file=/etc/kubernetes/audit-policy.yaml

9. Advanced Kubernetes

Custom Resource Definitions (CRDs)

Create a Custom Resource Definition:

apiVersion: apiextensions.k8s.io/v1
kind: CustomResourceDefinition
metadata:
  name: myresources.example.com
spec:
  group: example.com
  versions:
  - name: v1
    served: true
    storage: true
    schema:
      openAPIV3Schema:
        type: object
        properties:
          spec:
            type: object
  scope: Namespaced
  names:
    plural: myresources
    singular: myresource
    kind: MyResource
    shortNames:
    - mr

Operators

Introduction to Operators: Operators are Kubernetes applications designed to manage complex stateful applications by extending the Kubernetes API.

Creating an Operator:

Use the Operator SDK to scaffold and build an operator.

operator-sdk init --domain=example.com --repo=github.com/example/memcached-operator
operator-sdk create api --group=cache --version=v1 --kind=Memcached --resource --controller

Service Mesh with Istio

Install Istio:
```
istioctl install --set profile=demo
```
Deploy an Application with Istio:
- Annotate namespace to enable Istio sidecar injection.
```
kubectl label namespace mynamespace istio-injection=enabled
```
- Deploy application in the annotated namespace.

Traffic Management with Istio:

Create VirtualService and DestinationRule to manage traffic routing.

apiVersion: networking.istio.io/v1alpha3
kind: VirtualService
metadata:
  name: myapp
spec:
  hosts:
  - myapp.example.com
  http:
  - route:
    - destination:
        host: myapp
        subset: v1

Monitoring and Logging

Prometheus and Grafana:

Install Prometheus:

kubectl apply -f https://github.com/prometheus-operator/prometheus-operator/blob/main/bundle.yaml

Install Grafana:

kubectl apply -f https://raw.githubusercontent.com/grafana/grafana/main/deploy/kubernetes/grafana-deployment.yaml

View Metrics in Grafana: Access the Grafana dashboard and configure data sources to use Prometheus.

Logging with ELK Stack:
- Deploy ELK Stack: Use Helm or custom YAML manifests to deploy Elasticsearch, Logstash, and Kibana.
```
helm install elk-stack stable/elastic-stack
```
- Configure Fluentd for Log Collection:
  - Deploy Fluentd as a DaemonSet to collect logs from all nodes and send them to Elasticsearch.

High Availability and Disaster Recovery

Kubernetes High Availability (HA):
- HA Master Nodes: Set up multiple master nodes to ensure availability.
- HA etcd Cluster: Use an HA etcd cluster to store Kubernetes state with redundancy.
Disaster Recovery:
- Backup and Restore etcd:
  - Use etcdctl to take snapshots of the etcd cluster.
```
etcdctl snapshot save /path/to/backup
```
  - Restore from the snapshot when needed.

Federation

Multi-Cluster Federation:
- Set Up Federation: Use Kubernetes Federation v2 to manage multiple clusters from a single control plane.
```
kubefedctl join mycluster --cluster-context=mycluster-context --host-cluster-context=host-cluster-context
```
- Deploy Federated Resources: Deploy resources that span across multiple clusters using the Federation API.
