CloudWatch Cheatsheet

text

Amazon CloudWatch is a comprehensive monitoring and management service designed for AWS and hybrid cloud applications. This guide covers everything from basic concepts to advanced configurations, helping you leverage CloudWatch for performance monitoring, troubleshooting, and operational insights.

1. Introduction to CloudWatch

What is CloudWatch?

  • Amazon CloudWatch is a monitoring and observability service for AWS resources and custom applications.
  • Provides actionable insights through metrics, logs, alarms, and dashboards.
  • Supports both infrastructure and application-level monitoring.

Key Features:

  • Metrics: Collect and monitor key performance data.
  • Logs: Aggregate, analyze, and search logs.
  • Alarms: Set thresholds for metrics to trigger automated actions.
  • Dashboards: Visualize data in real time.
  • CloudWatch Events: Trigger actions based on changes in AWS resources.

2. CloudWatch Architecture Overview

  • Data Sources:
    • AWS Services: EC2, RDS, Lambda, etc.
    • On-premises servers or hybrid setups using CloudWatch Agent.
  • Core Components:
    • Metrics: Quantifiable data points (e.g., CPU utilization).
    • Logs: Application and system logs.
    • Alarms: Notifications or automated responses.
    • Dashboards: Custom visualizations.
    • Insights: Advanced log analytics.

3. Setting Up CloudWatch

Accessing CloudWatch

  1. Go to the AWS Management Console.
  2. Navigate to CloudWatch under the Management & Governance section.

CloudWatch Agent Installation

To monitor custom metrics or on-premises resources:

  1. Install the CloudWatch Agent on your instance:

    sudo yum install amazon-cloudwatch-agent

  2. Configure the agent:

    sudo /opt/aws/amazon-cloudwatch-agent/bin/amazon-cloudwatch-agent-config-wizard

  3. Start the agent:

    sudo /opt/aws/amazon-cloudwatch-agent/bin/start-amazon-cloudwatch-agent

Setting IAM Permissions

Attach the CloudWatchFullAccess policy to the IAM role or user managing CloudWatch.

4. Metrics Monitoring

Viewing Metrics

  1. In the CloudWatch console, go to Metrics.
  2. Select a namespace (e.g., AWS/EC2, AWS/Lambda).
  3. Choose metrics like CPUUtilization, DiskWriteOps, etc.

Common Metrics:

  • EC2:
    • CPUUtilization
    • DiskReadBytes
    • NetworkIn/Out
  • RDS:
    • DatabaseConnections
    • ReadIOPS
    • WriteLatency
  • Lambda:
    • Invocations
    • Duration
    • Errors

Custom Metrics

To send custom metrics:

  1. Install the AWS CLI.

  2. Publish a metric:

    aws cloudwatch put-metric-data --namespace "CustomNamespace" --metric-name "MetricName" --value 100

5. CloudWatch Logs

Setting Up Log Groups and Streams

  1. Navigate to Logs in the CloudWatch console.
  2. Create a Log Group (e.g., /aws/lambda/my-function).
  3. Each application/service writes to a Log Stream under the group.

Exporting Logs to S3

  1. Go to Logs → Select a log group.
  2. Click Actions → Export data to Amazon S3.
  3. Configure the export with the desired time range.

Querying Logs with CloudWatch Logs Insights

  1. Navigate to Logs Insights.

  2. Write queries for analysis:

    fields @timestamp, @message
| filter @message like /ERROR/
| sort @timestamp desc
| limit 20

6. CloudWatch Alarms

Creating an Alarm

  1. Go to Alarms in the CloudWatch console.
  2. Click Create Alarm.
  3. Select a metric (e.g., CPUUtilization).
  4. Set a threshold (e.g., > 80% for 5 minutes).
  5. Choose an action (e.g., send an SNS notification).

Alarm States:

  • OK: Metric is within the defined threshold.
  • ALARM: Metric breaches the threshold.
  • INSUFFICIENT DATA: No data available.

Advanced Alarm Configurations

  • Composite Alarms: Combine multiple alarms.
  • Actions:
    • Notify via SNS.
    • Trigger Lambda functions.
    • Stop/start EC2 instances.

7. CloudWatch Dashboards

Creating a Dashboard

  1. Go to Dashboards in the CloudWatch console.
  2. Click Create Dashboard.
  3. Add widgets:
    • Line for metrics.
    • Number for single values.
    • Text for notes.

Customizing Widgets

  • Choose metrics from different namespaces.
  • Configure time ranges and granularity.

Example: Multi-Service Dashboard

  • EC2 Metrics: CPU, Disk, Network.
  • RDS Metrics: Connections, IOPS.
  • Lambda Metrics: Invocations, Errors.

8. CloudWatch Events (EventBridge)

Creating Rules

  1. Navigate to Rules under Events in the CloudWatch console.
  2. Create a rule with an event pattern (e.g., EC2 state change).
  3. Add a target (e.g., SNS, Lambda, Step Functions).

Example: Automate Instance Shutdown

  1. Event Pattern:

    {
  "source": ["aws.ec2"],
  "detail-type": ["EC2 Instance State-change Notification"],
  "detail": {
    "state": ["stopped"]
  }
}

  2. Target: Send an SNS notification.

9. Advanced Configurations

Cross-Account Monitoring

  1. Create a cross-account role with permissions to access CloudWatch in the target account.
  2. Use the CloudWatch:ListMetrics and CloudWatch:GetMetricData APIs.

Anomaly Detection

Enable anomaly detection for metrics:

  1. Go to Metrics → Select a metric.
  2. Click Actions → Enable anomaly detection.

Metric Math

Perform calculations across metrics:

  • Example: Combine CPU utilization across instances.

    (m1+m2)/2

10. Integration with Other Services

AWS Lambda

  • Use console.log() to write logs to CloudWatch.
  • Monitor Lambda-specific metrics like Errors and Throttles.

ECS/EKS

  • Enable CloudWatch Container Insights for detailed monitoring.
  • Use awslogs driver to send container logs to CloudWatch.

Integration with Third-Party Tools

  • Use DataDog or Grafana for enhanced visualization.
  • Integrate CloudWatch metrics into these platforms using APIs.

11. Security Best Practices

Log Retention

  • Set retention policies for logs to reduce costs:

    aws logs put-retention-policy --log-group-name "/aws/lambda/my-function" --retention-in-days 30

Fine-Grained Access Control

  • Use IAM policies to restrict access to specific metrics, logs, or dashboards.

12. CloudWatch Pricing

Pricing Model

  1. Metrics: Charged per metric, per month.
  2. Logs:
    • Ingestion: Cost per GB ingested.
    • Storage: Cost per GB stored.
  3. Dashboards: Charged per dashboard, per month.

Cost Optimization Tips

  • Use metric filters to limit data collection.
  • Set shorter retention periods for logs.

13. Best Practices

  1. Organize Log Groups:

    • Use consistent naming conventions (e.g., /application/environment/service).

  2. Use Alarms Wisely:

    • Avoid too many alarms to prevent alert fatigue.
    • Use composite alarms to group related metrics.

  3. Automate Monitoring:

    • Automate alert creation and dashboards using CloudFormation or Terraform.

  4. Optimize Log Storage:

    • Export logs to S3 for long-term storage and analysis.

  5. Enable Anomaly Detection:

    • Automate anomaly detection for critical metrics.
