Grafana Cheatsheet

text

1. Introduction:

  • Grafana is an open-source platform for monitoring and observability that allows you to query, visualize, and alert on metrics from multiple data sources like Prometheus, InfluxDB, Elasticsearch, and more.

2. Key Concepts:

  • Dashboard: A collection of panels organized into a grid.
  • Panel: A visualization of data (graphs, charts, etc.) from a specific data source.
  • Data Source: The database or service that provides the metrics for Grafana to visualize.
  • Alerting: Set up conditions to trigger notifications when metrics meet specific criteria.

3. Installation:

  • Running Grafana:

    sudo apt-get install -y adduser libfontconfig1
wget https://dl.grafana.com/oss/release/grafana_7.5.7_amd64.deb
sudo dpkg -i grafana_7.5.7_amd64.deb
sudo systemctl start grafana-server
sudo systemctl enable grafana-server

  • Docker:

    docker run -d -p 3000:3000 --name=grafana grafana/grafana

4. Configuring Data Sources:

  • Adding Prometheus as a Data Source:

    1. Navigate to Configuration > Data Sources.
    2. Click on Add data source and select Prometheus.
    3. Enter the URL of your Prometheus server (e.g., http://localhost:9090).
    4. Click Save & Test to verify the connection.

  • Adding Elasticsearch as a Data Source:

    1. Navigate to Configuration > Data Sources.
    2. Click on Add data source and select Elasticsearch.
    3. Enter the URL, index name, and time field.
    4. Click Save & Test to verify the connection.

5. Building Dashboards:

  • Creating a New Dashboard:

    1. Click the + icon in the sidebar and select Dashboard.
    2. Click Add new panel.
    3. Choose your data source and write a query (e.g., rate(http_requests_total[5m]) for Prometheus).
    4. Select a visualization type (e.g., Graph, Stat, Gauge).
    5. Save the panel and the dashboard.

  • Using Variables:

    • Creating a Variable:
      1. Go to Dashboard settings > Variables > New.
      2. Set the Name, Type (e.g., Query), and Query.
      3. Use the variable in panel queries by referencing it as $variable_name.

6. Alerting:

  • Creating Alerts:

    1. Add a panel to your dashboard.
    2. In the Alert tab, click Create Alert.
    3. Set the Conditions for triggering the alert (e.g., when a metric crosses a threshold).
    4. Define the Evaluation Interval and No Data options.
    5. Configure Notifications to send alerts via email, Slack, or other channels.

  • Managing Alerts:

    • Alerts can be managed centrally through the Alerting section in the sidebar.

7. Grafana Plugins:

  • Installing Plugins:

    grafana-cli plugins install grafana-piechart-panel
sudo systemctl restart grafana-server

  • Popular Plugins:

    • Pie Chart Panel: Display metrics in a pie chart.
    • Worldmap Panel: Visualize data on a world map.
    • Alert List Panel: Display active alerts from multiple sources.

8. Dashboard Templating:

  • Using Templated Dashboards:

    • Leverage variables to create dynamic dashboards that can change based on user input.

  • Dynamic Panels:

    • Create repeating panels or rows based on variable values (e.g., show metrics per host).

9. Customizing Grafana:

  • Themes:

    • Switch between light and dark themes via Preferences in the dashboard settings.

  • Custom Branding:

    • Modify Grafana's appearance by adding custom logos and colors. Requires editing configuration files and CSS.

10. Securing Grafana:

  • User Management:

    • Add users and assign them roles such as Viewer, Editor, or Admin.

  • LDAP/SSO Integration:

    • Configure Grafana to use LDAP or Single Sign-On (SSO) for user authentication.

  • Enabling HTTPS:

    [server]
protocol = https
cert_file = /path/to/cert.crt
cert_key = /path/to/cert.key

11. Advanced Queries and Visualizations:

  • Grafana with PromQL:

    • Use advanced PromQL queries for more complex visualizations.

  • Annotations:

    • Add annotations to mark specific events on graphs, useful for correlating issues with changes or incidents.

12. Grafana Loki:

  • Introduction to Loki:

    • Grafana Loki is a horizontally scalable, highly available log aggregation system inspired by Prometheus.

  • Setting up Loki:

    docker run -d --name=loki -p 3100:3100 grafana/loki:2.2.0 -config.file=/etc/loki/local-config.yaml

  • Querying Logs in Grafana:

    • Use Loki as a data source to query and visualize logs alongside metrics.

13. Grafana in Kubernetes:

  • Deploying Grafana in Kubernetes:

    apiVersion: apps/v1
kind: Deployment
metadata:
  name: grafana
spec:
  replicas: 1
  selector:
    matchLabels:
      app: grafana
  template:
    metadata:
      labels:
        app: grafana
    spec:
      containers:
      - name: grafana
        image: grafana/grafana:7.5.7
        ports:
        - containerPort: 3000

14. Troubleshooting Grafana:

  • Common Issues:

    • No Data: Check data source configuration and queries.
    • Slow Dashboards: Optimize queries and reduce the time range.
    • Plugin Errors: Ensure plugins are compatible with your Grafana version.

  • Debugging:

    • View logs at /var/log/grafana/grafana.log for error details.
    • Use curl to test data source connectivity (e.g., curl http://localhost:9090 for Prometheus).
