Federated Machine Learning with Filecoin EVM

This project combines federated machine learning (using Flower) with on-chain model deployment via the Filecoin Ethereum Virtual Machine (FEVM). It trains a CNN on CIFAR-10 across 16 simulated clients using federated averaging, exports the model to ONNX, and provides Solidity smart contracts for model service and Filecoin storage deal management.

Project Structure

FML_with_FEVM_Workshop/
├── fml_fevm/                          # Python package (FL + model)
│   ├── model.py                       # CNN architecture (Net)
│   ├── data.py                        # CIFAR-10 loading & partitioning
│   ├── utils.py                       # Training, testing, parameter helpers
│   ├── export.py                      # ONNX export & bytecode conversion
│   ├── optimization.py                # Pruning, quantization, profiling
│   └── federated/                     # Flower-based FL components
│       ├── client.py                  # FlowerClient implementation
│       ├── compressed_client.py       # Client with gradient compression
│       ├── compression.py             # Sparse gradient utilities
│       ├── strategy.py                # FedAvg + optimized strategy configs
│       ├── simulation.py              # FL simulation runner
│       ├── byzantine.py               # Byzantine-robust median aggregation
│       ├── profiling.py               # Communication profiling & analysis
│       └── tuning.py                  # Local epoch tuning utilities
├── FML_Model/
│   ├── FML_with_FEVM_Workshop.ipynb   # Original workshop notebook
│   └── optimization_benchmark.ipynb   # Optimization benchmark notebook
├── contracts/
│   ├── basic-solidity-examples/
│   │   └── ModelService.sol           # On-chain model service proxy
│   ├── filecoin-api-examples/
│   │   ├── DealRewarder.sol           # Storage deal bounty contract
│   │   └── FilecoinMarketConsumer.sol # Market data consumer
│   └── basic-deal-client/
│       └── DealClient.sol             # Filecoin storage deal client
├── deploy/                            # Hardhat deployment scripts
├── tasks/                             # Hardhat task scripts
├── docs/                              # Project documentation
├── tests/                             # Test suites
│   ├── python/                        # pytest: model, data, optimization, compression, export, profiling, tuning, byzantine
│   └── solidity/                      # Hardhat: ModelService, DealRewarder, DealClient
├── model.onnx                         # Exported ONNX model
├── model_onnx_bytecode.txt            # Model bytecode for on-chain reference
├── requirements.txt                   # Python dependencies
├── pyproject.toml                     # Python build configuration
├── package.json                       # Node.js dependencies
└── hardhat.config.js                  # Hardhat configuration

Part 1: Federated Machine Learning Model

Using the Notebook

The workshop notebook is available at FML_Model/FML_with_FEVM_Workshop.ipynb. For GPU access and pre-installed dependencies, upload it to Google Colab or run it in a local environment with the required packages installed.

Using the Python Package

The fml_fevm package provides the same functionality as the notebook in a modular, importable format:

pip install -r requirements.txt

from fml_fevm.model import Net
from fml_fevm.data import load_datasets
from fml_fevm.utils import train, test, DEVICE
from fml_fevm.federated import run_simulation
from fml_fevm.export import export_to_onnx, onnx_to_bytecode, save_bytecode

# Train centrally
trainloaders, valloaders, testloader = load_datasets()
net = Net().to(DEVICE)
train(net, trainloaders[0], epochs=5, verbose=True)
loss, accuracy = test(net, testloader)

# Or run federated simulation
history = run_simulation(num_clients=16, num_rounds=5)

# Export to ONNX and generate bytecode
onnx_path = export_to_onnx(net)
bytecode = onnx_to_bytecode(onnx_path)
save_bytecode(bytecode)

Model Details

• Architecture: Small CNN (~62K parameters) — 2 conv layers + 3 fully connected layers
• Dataset: CIFAR-10 (10-class image classification)
• FL Setup: 16 simulated clients, FedAvg strategy, 5 training rounds
• Export: ONNX format with bytecode conversion for on-chain reference

Optimization

The optimization_benchmark.ipynb notebook (in FML_Model/) benchmarks the full optimization pipeline. The fml_fevm.optimization module and fml_fevm.federated.compression module provide:

• Model pruning — L1 unstructured pruning on fc layers (fc1 50%, fc2 30%), targeting the 77% of parameters in fc1
• Dynamic quantization — INT8 quantization on all linear layers for smaller model size and faster inference
• Gradient compression — Top-k sparsification of gradient deltas, transmitting only the most significant updates per FL round
• Compressed FL client — CompressedFlowerClient combines sparse gradients with multiple local epochs, reducing both per-round bandwidth and total rounds needed

from fml_fevm.optimization import apply_pruning, make_pruning_permanent, apply_dynamic_quantization
from fml_fevm.federated.compressed_client import compressed_client_fn, set_compressed_config

# Prune and quantize a trained model
apply_pruning(net, fc1_amount=0.5, fc2_amount=0.3)
make_pruning_permanent(net)
quantized = apply_dynamic_quantization(net)

# Run FL with gradient compression
set_compressed_config(trainloaders, valloaders, keep_ratio=0.3, local_epochs=3)

FL Pipeline Optimization

The fml_fevm.federated package includes communication-optimized FL with tunable hyperparameters:

• Optimized strategy — create_optimized_strategy() samples 10 of 16 clients per round (37.5% fewer communications)
• Optimized simulation — run_optimized_simulation() combines compressed clients, tuned sampling, and fewer rounds
• Communication profiling — profiling.py calculates baseline vs compressed byte counts and reduction percentages
• Local epoch tuning — tuning.py estimates rounds needed and communication savings for different configurations

from fml_fevm.federated import run_optimized_simulation, create_optimized_strategy
from fml_fevm.federated.tuning import recommended_config, communication_savings

# Get recommended FL hyperparameters
config = recommended_config()  # local_epochs=3, keep_ratio=0.3, fraction_fit=0.625

# Run optimized FL (3 rounds instead of 5, compressed gradients, partial participation)
history = run_optimized_simulation(num_rounds=3, keep_ratio=0.3, local_epochs=3)

Security: Byzantine-Robust FL

The byzantine.py module implements coordinate-wise median aggregation to defend against model poisoning attacks:

• Median aggregation — Filters out extreme/poisoned gradient updates from malicious clients
• Tolerance — Resists up to floor(n/2) - 1 Byzantine clients (7 of 16)
• Poisoning simulation — simulate_poisoning_attack() for testing defense effectiveness

from fml_fevm.federated.byzantine import create_byzantine_strategy, simulate_poisoning_attack

# Create a Byzantine-robust strategy
robust_strategy = create_byzantine_strategy(max_malicious_fraction=0.5)

Part 2: Smart Contracts & Deploying to FEVM

Setup

git clone https://github.com/TechieTeee/FML_with_FEVM_Workshop.git
cd FML_with_FEVM_Workshop
yarn install

Get a Private Key

You can get a private key from a wallet provider such as Metamask.

Add your Private Key as an Environment Variable

export PRIVATE_KEY='abcdef'

Or create a .env file (already in .gitignore). Never commit your private key.

Get the Deployer Address

yarn hardhat get-address

This shows your Ethereum-style address and Filecoin f4 address.

Fund the Deployer Address

Go to the Hyperspace testnet faucet and paste your Ethereum address.

Deploy the Contracts

yarn hardhat deploy

This compiles and deploys all contracts to the Hyperspace testnet:

• ModelService — On-chain model service proxy with owner access control and event logging (ModelUpdated, PredictionRequested). After deployment, call setModel(address) to link a model contract.
• FilecoinMarketConsumer — Queries and stores Filecoin storage deal data via the MarketAPI, with owner access control.
• DealRewarder — Creates bounties for storing specific data on Filecoin, with event logging (CIDAdded, BountyClaimed, DataAuthorized) and hardened access control.
• DealClient — Creates Filecoin storage deals from Solidity with reentrancy protection, emitting events for Boost storage providers.

Interact with Contracts

Use Hardhat tasks in the tasks/ folder:

yarn hardhat get-balance --contract 'DEPLOYED_ADDRESS' --account 'YOUR_ADDRESS'

Filecoin APIs

The project uses the Filecoin.sol library by Zondax to interact with Filecoin storage deals on-chain. Example:

yarn hardhat store-all --contract "DEPLOYED_MARKET_CONSUMER_ADDRESS" --dealid "707"

Preparing Data for Storage

Files must be converted to .car format before storage. Use the FVM Data Depot for automatic conversion and metadata generation.

More on the Contracts

• DealClient: Creates storage deals via Solidity. See the deal-making starter kit for details.
• DealRewarder: Incentivizes data storage with bounties. See the original Foundry project for details.

Testing

Solidity Tests

Run on the local Hardhat network (no private key or testnet needed):

PRIVATE_KEY="0x0000000000000000000000000000000000000000000000000000000000000001" npx hardhat test tests/solidity/ModelService_test.js --network hardhat
PRIVATE_KEY="0x0000000000000000000000000000000000000000000000000000000000000001" npx hardhat test tests/solidity/DealRewarder_test.js --network hardhat
PRIVATE_KEY="0x0000000000000000000000000000000000000000000000000000000000000001" npx hardhat test tests/solidity/DealClient_test.js --network hardhat

ModelService (10 tests): Ownership, setModel access control, zero address rejection, predict-without-model revert, ModelUpdated event emission, ownership transfer prevention.

DealRewarder (8 tests): Ownership, addCID access control, authorizeData internal verification, fund deposits, CIDAdded event, security (call_actor_id internal, authorizeData internal).

DealClient (4 tests): Ownership, access control on makeDealProposal, initial deal count, reentrancy guard validation.

Python Tests

Requires PyTorch and dependencies (pip install -r requirements.txt):

pytest tests/python/

test_model (8 tests): Output shape, batch sizes, param count, fc1 dominance, deterministic output, parameter get/set roundtrip.

test_data (9 tests): Partition count, no overlap across clients, train/val split ratio, image shape, label range, seed reproducibility.

test_optimization (10 tests): Profiling accuracy, pruning sparsity, quantization output validity, prune+quantize pipeline, inference benchmark.

test_compression (17 tests): Threshold sparsification, top-k keeps largest values, delta roundtrip, transmission size estimation, keep_ratio validation edge cases.

test_export (5 tests): ONNX file creation, ONNX validity, PyTorch-ONNX output match, bytecode hex format, bytecode-to-file-size match.

test_profiling (12 tests): Communication profile metrics, compression byte reduction, local epoch round reduction, FL config participation, report formatting, edge cases (zero epochs, zero rounds).

test_tuning (15 tests): Round estimation with local epochs, communication savings calculations, reduction percentages, recommended config validation, edge cases (zero epochs, zero clients).

test_byzantine (13 tests): Median aggregation (odd/even/single clients), poisoning attack rejection, majority-poisoned failure, strategy creation, parameter aggregation, empty input guard.

test_strategy (4 tests): Weighted average normal case, empty metrics, single client, equal weights.

License

MIT
