Agentic AI Template

Enterprise-ready AI agent template with multi-tenant architecture

Features • Quick Start • Architecture • Tech Stack • Documentation

Python 3.11+ React 19.2 FastAPI LangGraph License

AI Chat Interface Memory Management

Real-time streaming chat with AI agents • Semantic memory with automatic extraction

Watch Demo Video

📺 Watch the full demo video

📦 Minimal Edition

Due to the high cost of RAM, this is a minimal version of the original template designed to reduce the compute footprint. External services like Langfuse (LLM observability), Infisical (secrets management), and OpenSearch (log aggregation) have been replaced with built-in alternatives:

  • Secrets → Encrypted PostgreSQL storage (Fernet/AES-128-CBC)
  • Audit Logs → PostgreSQL tables + JSON file backup
  • LLM Tracing → Removed (agents work without it)

This reduces memory usage from ~8GB to ~2GB while maintaining all core functionality.

Overview

A production-ready full-stack AI agent template built for teams and enterprises. Features real-time streaming chat with LangGraph agents, MCP (Model Context Protocol) tool integration, semantic memory with pgvector, hierarchical multi-tenancy (Organizations → Teams → Users), and enterprise integrations for secrets management, audit logging, and LLM observability.

Why This Template?

  • Multi-Tenant by Design: Built from the ground up with proper data isolation between organizations and teams
  • MCP Tool Integration: Connect external tools via Model Context Protocol with human-in-the-loop approval
  • Semantic Memory: Persistent user memory with embedding-based search and deduplication
  • Real-Time AI Streaming: SSE-powered chat with graceful cancellation and state persistence
  • Multi-Provider LLM Support: Switch between Anthropic, OpenAI, and Google at the org or team level
  • Enterprise Security: JWT auth, RBAC, audit logging, secrets management, and compliance-ready architecture
  • Developer Experience: One-command setup, hot reload, auto-generated API docs, type-safe modular API client

Features

AI & Agent Capabilities

  • LangGraph ReAct Agent — Graph-based agent with PostgreSQL state checkpointing
  • Multi-Provider LLM — Anthropic Claude Haiku 4.5, OpenAI GPT-4o, Google Gemini 2.0 Flash
  • SSE Streaming — Real-time token streaming with browser-native cancellation
  • Hierarchical Prompts — System prompts at org, team, and user levels (auto-concatenated)
  • Semantic Memory — Persistent user context with pgvector embeddings and deduplication
  • MCP Tool Integration — Connect external HTTP/SSE tools with approval workflow
  • Audit Logging — PostgreSQL-based audit logging with frontend viewer

MCP (Model Context Protocol)

  • Multi-Scope Servers — Configure at organization, team, or user level
  • Transport Support — HTTP, SSE, and Streamable HTTP protocols
  • Auth Options — None, Bearer token, or API key authentication
  • Human-in-the-Loop — Configurable tool approval before execution
  • Tool Management — Enable/disable servers and individual tools per hierarchy level
  • Connection Testing — Verify server connectivity before use

Multi-Tenant Architecture

  • Organizations — Top-level tenant boundaries with roles (Owner, Admin, Member)
  • Teams — Sub-groups within organizations with granular permissions
  • Hierarchical Settings — Chat, memory, and MCP settings cascade org → team → user
  • Invitations — Email-based invites with secure token validation
  • Per-Team API Keys — Store LLM credentials per team (encrypted in database)

Enterprise Features

  • RBAC — 22 org permissions + 17 team permissions with role-based mappings
  • Audit Logging — PostgreSQL-based with configurable retention (90 days default)
  • Secrets Management — Encrypted database storage using Fernet (AES-128-CBC)
  • Rate Limiting — Configurable limits per endpoint category
  • Security Headers — CORS, CSP, HSTS, XSS protection

Developer Experience

  • Auto-Generated Docs — OpenAPI/Swagger at /v1/docs
  • Modular API Client — Domain-specific TypeScript modules with full type safety
  • Hot Reload — Both backend and frontend with instant updates
  • Setup Scripts — One-command infrastructure + migrations

Quick Start

Prerequisites

  • Docker & Docker Compose
  • Python 3.11+ with uv
  • Node.js 20+

Option 1: Automated Setup (Recommended)

# Clone the repository
git clone https://github.com/davidgaribay-dev/agentic-ai-template.git
cd agentic-ai-template

# Run setup (starts infrastructure, runs migrations)
./setup-local.sh

# Start dev servers in separate terminals
cd backend && uv run uvicorn backend.main:app --reload    # Terminal 1: API on :8000
cd frontend && npm run dev                                  # Terminal 2: UI on :5173

Option 2: Manual Setup

# Start infrastructure services
docker compose -f docker-compose-local.yml up -d

# Backend setup
cd backend
uv sync
uv run alembic upgrade head
uv run uvicorn backend.main:app --reload

# Frontend setup (new terminal)
cd frontend
npm install
npm run dev

Access Points

Service URL Description
Frontend http://localhost:5173 React application
API http://localhost:8000 FastAPI backend
API Docs http://localhost:8000/v1/docs Swagger/OpenAPI

Default Credentials

  • Superuser: admin@example.com / changethis

Architecture

System Overview

┌─────────────────────────────────────────────────────────────────────┐
│                         Frontend (React 19)                          │
│  ┌──────────┐  ┌───────────────┐  ┌───────────┐  ┌───────────────┐  │
│  │ TanStack │  │   SSE Chat    │  │  Zustand  │  │   shadcn/ui   │  │
│  │  Router  │  │   Streaming   │  │   Store   │  │   Components  │  │
│  └──────────┘  └───────────────┘  └───────────┘  └───────────────┘  │
└───────────────────────────────┬─────────────────────────────────────┘
                                │ /api/* proxy
                                ▼
┌─────────────────────────────────────────────────────────────────────┐
│                        Backend (FastAPI)                             │
│  ┌──────────┐  ┌───────────────┐  ┌───────────┐  ┌───────────────┐  │
│  │   REST   │  │   LangGraph   │  │    MCP    │  │   Memory      │  │
│  │   API    │  │   Agent       │  │   Tools   │  │   Store       │  │
│  └──────────┘  └───────────────┘  └───────────┘  └───────────────┘  │
└────────┬───────────────┬─────────────────┬──────────────┬───────────┘
         │               │                 │              │
         ▼               ▼                 ▼              ▼
┌─────────────────────────────────────────────┐  ┌───────────┐
│       PostgreSQL + pgvector                  │  │ SeaweedFS │
│  (Data + Audit Logs + Encrypted Secrets)    │  │   (S3)    │
└─────────────────────────────────────────────┘  └───────────┘

Multi-Tenant Data Model

Organization (tenant boundary)
├── OrganizationMember
│   └── role: OWNER | ADMIN | MEMBER
├── Team (sub-group)
│   └── TeamMember
│       └── role: ADMIN | MEMBER | VIEWER
├── Conversation (scoped to org + team)
├── Prompt (hierarchical: org → team → user)
├── MCP Servers (hierarchical: org → team → user)
├── Chat Settings (hierarchical: org → team → user)
├── Memory (scoped to org + team + user)
└── API Keys (encrypted in database)

Project Structure

├── setup.sh                    # Full setup (CI/first-time)
├── setup-local.sh              # Local dev setup
├── docker-compose.yml          # Full stack containers
├── docker-compose-local.yml    # Infrastructure only
├── tests/                      # Playwright E2E tests
│   ├── tests/
│   │   ├── api/                # API tests (no browser)
│   │   ├── auth/               # Auth UI tests
│   │   ├── teams/              # Team management tests
│   │   └── invitations/        # Invitation flow tests
│   ├── pages/                  # Page objects
│   ├── utils/                  # Test utilities
│   └── playwright.config.ts
│
├── backend/
│   ├── src/backend/
│   │   ├── agents/             # LangGraph agent, tools, LLM providers
│   │   ├── mcp/                # MCP server registry, client, tool loading
│   │   ├── memory/             # Semantic memory store with pgvector
│   │   ├── api/routes/         # REST endpoints (/v1 prefix)
│   │   ├── auth/               # JWT, user model, dependencies
│   │   ├── rbac/               # Permissions, role mappings
│   │   ├── organizations/      # Org + member management
│   │   ├── teams/              # Team + member management
│   │   ├── conversations/      # Chat history (soft delete)
│   │   ├── prompts/            # System prompts (org/team/user)
│   │   ├── settings/           # Chat settings hierarchy
│   │   ├── audit/              # PostgreSQL audit logging
│   │   └── core/               # Config, DB, security, encrypted secrets
│   ├── tests/                  # Unit + integration tests (pytest)
│   ├── scripts/                # Setup automation
│   └── alembic/                # Database migrations
│
└── frontend/
    └── src/
        ├── routes/             # File-based routing (auto-gen)
        ├── components/
        │   ├── ui/             # shadcn/ui components
        │   ├── chat/           # Chat UI, markdown, code blocks
        │   └── settings/       # Settings panels
        ├── hooks/              # useChat, useAuth, useWorkspace
        └── lib/
            ├── api/            # Modular API client
            │   ├── agent.ts
            │   ├── auth.ts
            │   ├── conversations.ts
            │   ├── mcp-servers.ts
            │   ├── memory.ts
            │   ├── chat-settings.ts
            │   └── ...
            ├── auth.ts         # Token management
            └── workspace.tsx   # Org/team context

Tech Stack

Backend

Technology Version Purpose
FastAPI 0.124+ Async REST API with auto-docs
SQLModel 0.0.27 ORM (SQLAlchemy + Pydantic)
PostgreSQL 17 Primary database (with pgvector)
LangGraph 0.6+ Agent orchestration with state
LangChain 0.3+ LLM provider integrations
Alembic 1.16+ Database migrations
Cryptography 41.0+ Secrets encryption (Fernet)

Frontend

Technology Version Purpose
React 19.2 UI framework (concurrent mode)
TypeScript 5.9 Type safety
Vite 7.2 Build tool
TanStack Router 1.141 File-based routing
TanStack Query 5.90 Server state management
Zustand 5.0 Client state
shadcn/ui Latest Component library
Tailwind CSS 4.1 Styling
Streamdown 1.6 Markdown streaming

Infrastructure

Service Port Purpose
PostgreSQL 5432 Application database (pgvector) + audit logs + encrypted secrets
SeaweedFS 8333 S3-compatible storage

Development

Commands

# Backend (from backend/)
uv run uvicorn backend.main:app --reload    # Dev server
uv run pytest                                # Run tests
uv run alembic revision --autogenerate -m "description"  # Create migration
uv run alembic upgrade head                  # Apply migrations

# Frontend (from frontend/)
npm run dev                   # Dev server with HMR
npm run build                 # Production build
npm run lint                  # ESLint
npx shadcn@latest add <name>  # Add UI component

# E2E Tests (from tests/)
npm run test                  # All E2E tests
npm run test:api-only         # API tests only
npm run test:ui-only          # UI tests only
npm run test:headed           # Visible browser
npm run report                # View HTML report

Environment Variables

Backend (backend/.env):

# Database
POSTGRES_SERVER=localhost
POSTGRES_PORT=5432
POSTGRES_USER=postgres
POSTGRES_PASSWORD=postgres
POSTGRES_DB=app

# Security
SECRET_KEY=your-secret-key    # Also used for secrets encryption
FRONTEND_URL=http://localhost:5173

# LLM Providers (optional - can be set via UI)
ANTHROPIC_API_KEY=sk-ant-...
OPENAI_API_KEY=sk-...
GOOGLE_API_KEY=...

# Audit logging
AUDIT_LOG_RETENTION_DAYS=90
APP_LOG_RETENTION_DAYS=30

Frontend (frontend/.env):

VITE_API_URL=http://localhost:8000
VITE_PORT=5173

Adding Features

Task Steps
New API Route Create in backend/api/routes/, add to api/main.py
New Page Add file to frontend/src/routes/ (auto-generates)
New DB Model Add SQLModel class, import in alembic/env.py, run migrations
New Agent Tool Add @tool function in backend/agents/tools.py
New MCP Server Add via UI at org/team/user settings, or via API
New API Module Add to frontend/src/lib/api/, export in index.ts

API Overview

Authentication

# Login (OAuth2 form-encoded)
curl -X POST http://localhost:8000/v1/auth/login \
  -d "username=admin@example.com&password=changethis"

# Use token
curl -H "Authorization: Bearer <token>" \
  http://localhost:8000/v1/users/me

Key Endpoints

Endpoint Description
POST /v1/auth/login OAuth2 login (form-encoded)
POST /v1/auth/signup Register + create org
GET /v1/organizations List user's orgs
GET /v1/conversations List conversations
POST /v1/agent/chat SSE streaming chat
GET /v1/prompts/* Manage system prompts
GET /v1/mcp-servers/* Manage MCP servers
GET /v1/memory/users/me/memories List user memories
GET /v1/settings/effective Get computed settings

Full documentation at http://localhost:8000/v1/docs

Security

  • Authentication: JWT tokens (30min access, 7-day refresh)
  • Password Hashing: bcrypt with timing-safe comparison
  • RBAC: Fine-grained org and team permissions (22 org + 17 team permissions)
  • Secrets: Encrypted in database using Fernet (AES-128-CBC)
  • MCP Auth: Bearer/API key secrets stored encrypted in PostgreSQL
  • Audit Trail: All actions logged to PostgreSQL (90-day retention)
  • Headers: CORS, CSP, HSTS, X-Frame-Options
  • Rate Limiting: Per-endpoint configurable limits

Contributing

  1. Fork the repository
  2. Create a feature branch (git checkout -b feature/amazing-feature)
  3. Commit changes (git commit -m 'Add amazing feature')
  4. Push to branch (git push origin feature/amazing-feature)
  5. Open a Pull Request

License

This project is licensed under the MIT License - see the LICENSE file for details.

About

No description, website, or topics provided.

Resources

Readme

License

MIT license
Activity

Stars

0 stars

Watchers

0 watching

Forks

0 forks
Report repository

Releases

No releases published

Packages





Contributors

Languages

Generated from davidgaribay-dev/agentic-ai-template
