GeoLibre Desktop

Lightweight, cloud-native desktop GIS prototype built with Tauri v2, React, TypeScript, MapLibre GL JS, DuckDB-WASM Spatial, and deck.gl.

Features (v0.6.0)

• MapLibre map workspace with OpenFreeMap basemaps, blank background support, and toggleable navigation, fullscreen, geolocation, globe, terrain, scale, attribution, and logo controls
• Load local vector layers supported by DuckDB-WASM Spatial, including common formats such as GeoJSON, GeoParquet, GeoPackage, Shapefile, FlatGeobuf, KML/KMZ, and GML
• Add Data menu for XYZ tiles, WMS, GeoJSON URLs, vector tiles, COG and GeoTIFF rasters, MBTiles, ArcGIS FeatureServer and VectorTileServer layers, PMTiles, Zarr, LiDAR, and Gaussian splats
• Layer panel for visibility, opacity, reordering, zoom-to-layer, identify, and remove actions
• Live style panel (fill, stroke, opacity, circle radius)
• Attribute table with filtering, sorting, resize controls, feature highlighting, and optional zoom to selected features
• Save/open .geolibre.json projects
• Processing toolbox with local bounds and feature count algorithms
• Plugin system with basemap, layer control, MapLibre components, swipe, street view, LiDAR, GeoAgent, and GeoEditor integrations, including configurable control positions
• Optional Python FastAPI sidecar for heavier processing workflows

Prerequisites

• Node.js 22+
• Rust toolchain (rustup) for Tauri desktop builds
• Linux: webkit2gtk, libayatana-appindicator (see Tauri prerequisites)

Install

git clone https://github.com/opengeos/GeoLibre.git
cd GeoLibre
npm install

Bun users can run bun install. The root trustedDependencies list allows the known install scripts for core-js, @google/genai, and protobufjs.

Run (web dev, map in browser)

npm run dev

Open http://localhost:5173. The map and browser vector import support local vector files that DuckDB-WASM Spatial can read, including common formats such as GeoJSON, GeoParquet, GeoPackage, Shapefile, FlatGeobuf, KML/KMZ, and GML, with direct handling for GeoJSON, zipped Shapefiles, and KMZ archives. You can choose files from Add Vector Layer or drag them onto the app. Desktop filesystem dialogs, local MBTiles, and local raster file reads require Tauri.

Embed the demo

The browser demo supports URL parameters for iframe-friendly layouts.

Open a project by URL:

https://geolibre.app/demo/?url=https://data.geolibre.app/opera-dswx.geolibre.json

Supported query parameters:

Parameter	Example	Description
url	url=https://data.geolibre.app/opera-dswx.geolibre.json	Loads a .geolibre.json project from a public URL.
layout	layout=compact	Uses the compact embed layout with icon-only toolbar buttons and hidden project metadata. embed and iframe are aliases.
toolbar	toolbar=icons	Shows icon-only toolbar buttons without enabling the full compact layout.
panels	panels=none	Hides the Layers, Style, and Attribute table panels. hidden, hide, and off are aliases.
hidePanels	hidePanels=true	Alternative way to hide the Layers, Style, and Attribute table panels.

Use compact mode for narrow embeds. This shows icon-only toolbar buttons and hides project metadata:

https://geolibre.app/demo/?url=https://data.geolibre.app/opera-dswx.geolibre.json&layout=compact

Hide the Layers, Style, and Attribute table panels for map-focused embeds:

https://geolibre.app/demo/?url=https://data.geolibre.app/opera-dswx.geolibre.json&layout=compact&panels=none

Use toolbar=icons when you only want icon-only toolbar buttons. panels=hidden, panels=hide, panels=off, and hidePanels=true are accepted aliases for hiding panels.

Environment variables

The Street View plugin can use Google Street View and Mapillary imagery. Create apps/geolibre-desktop/.env.local and set one or both provider credentials:

VITE_GOOGLE_MAPS_API_KEY=your_google_maps_api_key
VITE_MAPILLARY_ACCESS_TOKEN=your_mapillary_access_token

For Google Street View, enable the Maps Embed API for the key in Google Cloud. For Mapillary, create an app in the Mapillary developer dashboard and use its client access token.

Restart npm run dev or npm run tauri:dev after changing these values. Vite only exposes variables with the VITE_ prefix to the frontend.

Run (desktop)

npm run tauri:dev

Build

npm run build
npm run tauri:build

Optional Python sidecar

cd backend/geolibre_server
python -m venv .venv && source .venv/bin/activate
pip install -e .
uvicorn geolibre_server.app.main:app --host 127.0.0.1 --port 8765

Repository layout

apps/geolibre-desktop   # Tauri + React app
packages/core           # Types, store, project format
packages/map            # MapLibre integration
packages/ui             # Tailwind + shadcn/ui
packages/plugins        # Plugin API
packages/processing     # Algorithm registry
backend/geolibre_server # FastAPI sidecar
sample-data/            # Sample GeoJSON & project
docs/                   # Architecture & API docs

Add a plugin

Built-in plugins live in packages/plugins/src/plugins/ and are registered by the desktop app in apps/geolibre-desktop/src/hooks/usePlugins.ts. Map control plugins can expose a control position through getMapControlPosition() and setMapControlPosition() so the Plugins menu can move them between map corners.

1. Create a plugin file in packages/plugins/src/plugins/.

import type { GeoLibreAppAPI, GeoLibrePlugin } from "../types";

export const myPlugin: GeoLibrePlugin = {
  id: "my-plugin",
  name: "My Plugin",
  version: "0.1.0",
  activate: (app: GeoLibreAppAPI) => {
    app.setBasemap("https://example.com/style.json");
  },
  deactivate: () => {},
};

2. Export it from packages/plugins/src/index.ts.

export { myPlugin } from "./plugins/my-plugin";

3. Register it in apps/geolibre-desktop/src/hooks/usePlugins.ts.

import { myPlugin } from "@geolibre/plugins";

manager.registerAll([
  maplibreLayerControlPlugin,
  maplibreGeoAgentPlugin,
  maplibreGeoEditorPlugin,
  myPlugin,
]);

Plugins can use the app API to change basemaps, add GeoJSON layers, or attach MapLibre controls. For a MapLibre control plugin, add the package dependency, import its CSS in apps/geolibre-desktop/src/main.tsx, then call app.addMapControl(control, "top-left") in activate() and app.removeMapControl(control) in deactivate().

Built-in MapLibre controls such as Navigation, Fullscreen, Geolocate, Globe, Terrain, Scale, Attribution, and Logo are toggled from the desktop app's Controls menu. The same menu also opens Search, a standalone place search panel backed by the Components plugin. Keep project-specific controls such as Layer Control and Components in the plugin menu when they use the plugin API or need plugin lifecycle behavior.

The v0.6.0 Components plugin wraps maplibre-gl-components controls and wires their layer events into the GeoLibre store. It provides Add Data shortcuts for FlatGeobuf, PMTiles, Zarr, LiDAR, and Gaussian splats, while raster COG and GeoTIFF layers can also be added through the standard Add Raster Layer dialog.

If a third-party MapLibre control needs app-specific styling fixes, add scoped overrides in apps/geolibre-desktop/src/index.css instead of editing files in node_modules. Keep selectors limited to the plugin control class. For example, GeoEditor toolbar buttons need a local override because MapLibre's default control button CSS can override their flex centering:

.geo-editor-control .geo-editor-tool-button {
  align-items: center;
  display: flex !important;
  justify-content: center;
  line-height: 0;
  padding: 0;
}

.geo-editor-control .geo-editor-tool-button svg {
  display: block;
  flex: 0 0 auto;
  margin: 0;
}

Run checks before submitting changes:

npm run build
pre-commit run --all-files

Documentation

• Architecture
• Project format
• Plugin API
• Roadmap

License

MIT
